K330S OPS
The OPS version of the K330S bandsaw with integrated quick-stop braking system. For the fine portioning of larger quantities, the K330S OPS is equipped with a sliding table which can be folded down sideways for dissections. The K330S OPS is not only ideally suited for processing fresh and frozen hollow bones and meat cuts, but also offers a high level of operator safety thanks to the new Operator Protection System from KOLBE.
Technical Data
Specifications subject to change without notice. Dimensions may vary.
|
Motor rotary current (3Ph) |
230/400 Volt |
|
|
Saw band measurements |
2490 x 16 mm |
|
|
Cut height passage (max.) |
300 mm |
|
|
Cut side passage (max.) |
285 mm |
|
|
Cutting stroke (max.) |
296 mm |
|
|
External dimensions (W x D x H) |
775 x 840 x 1811 mm |
|
Wheel diameter |
300 mm |
|
|
Saw band measurements |
2490 x 16 mm |
|
|
Blade speed |
22 m/s |
|
|
Cut height passage (max.) |
300 mm |
|
|
Cut side passage (max.) |
285 mm |
|
|
Cutting stroke (max.) |
296 mm |
|
|
Section of portioning |
5 – 255 mm |
|
|
Table dimensions (W x D x H) |
590 x 765 x 911 mm |
|
|
External dimensions (W x D x H) |
775 x 840 x 1811 mm |
|
|
Motor capacity / Protection system IP54 |
1,5 kW |
|
|
Nominal current at 230 V / 400 V |
5,9 / 3,4 A |
|
|
Conductor size |
1,5 mm² |
|
|
Fusing at 230 V / 400 V (A lazy) |
16 / 16 A |
|
|
Noise level |
72 db (A) |
|
|
Compressed air connection |
6 – 10 bar |
The new KOLBE Operator Protection System based on the K330 bandsaw. The OPS series consists of powerful and compact safety bandsaws featuring a quick-stop braking system that, thanks to a high-speed camera, ensures a braking time of less than 5 milliseconds.
At the heart of the OPS series are five intelligent monitoring assistants:
1. Glove check-in assistant (system activation)
2. Glove detection assistant
3. Camera position monitoring
4. Camera contamination monitoring
5. Lighting monitoring
The safety bandsaw can only be started using the green gloves approved by KOLBE, which must first be checked in by the operator. User interaction is handled conveniently via a color display.
Additional key features include the low-wear and exceptionally quiet braking process. Since the saw blade is held in position during braking, no blade replacement is required and the machine can be restarted in less than one minute.
The OPS series is designed for daily, easy, and absolutely hygienic cleaning.
The bandsaw is available as a right sided, as well as left sided version. The K330 is also available as a mobile version with with 2 swivel and 2 fixed castors.
